🔥 Strumento compatto per training e grip – CQS MK.I (Design Concept)
📌 Description
When space is limited and grip control is critical, this compact design concept is intended for training activities, ergonomic study, and experimentation with grip retention.
The project focuses on:
- ergonomics under stress
- grip geometry
- structural strength in 3D printing
The grooves and curves are designed to improve control even when wearing gloves or with sweaty hands.
The internal arches reduce weight while maintaining rigidity and balance.
🔗 Reinforced lanyard hole for cord or retention ring
✅ Tested with PETG, ABS, ASA, and PA-CF
This model is a design and training concept and is not designed or promoted for offensive or harmful use.
⚙️ Specs
- 📐 Orientation: Vertical
- 📏 Layer Height: 0.20–0.28 mm
- 🧱 Walls: 6
- 🔝 Top/Bottom: 6
- 🔳 Infill: 100% (Gyroid or Concentric) (50% Gyroid optional for lighter carry)
- 🧵 Material: PETG / ABS / ASA / PA-CF
- 🔍 Nozzle: 0.6 mm (best) or 0.4 mm
- ⚖️ Weight: ~70 g for extra impact force
- 🚫 Supports: Not needed
⚠️ Safety: Training tool only. Use responsibly and legally.
⭐ Features
✔️ Ergonomic finger grooves for maximum control
✔️ Internal weight-reduction arches (better grip, balanced weight)
✔️ Solid striking tip (rounded & safe for training)
✔️ Reinforced lanyard hole (4–4.5 mm)
✔️ No supports required
✔️ Works with nozzle 0.4 mm or 0.6 mm (recommended 0.6)
✔️ Weight ~70 g → more impact without losing speed
🛠️ Print Settings
- 📐 Orientation: Vertical
- 📏 Layer Height: 0.20 mm (quality) or 0.28 mm (faster)
- 🧱 Walls: 6
- 🔝 Top/Bottom: 6
- 🔳 Infill: 100% Gyroid or Concentric
- 🧵 Material: PETG / ABS / ASA / PA-CF
- ❄️ Cooling: Low/moderate for better layer adhesion
- 🚫 Supports: None
📊 Material Quick Guide
| 🧵 Material | ✅ Pros | ❌ Cons | 💡 Notes |
|---|---|---|---|
| PETG | Tough, easy, good adhesion | More flexible than ABS | Great for general EDC |
| ABS | Rigid, smooth finish | Warping, fumes | Enclosure recommended |
| ASA | UV resistant, ABS-like | Cost, odor | Perfect for outdoor |
| PA-CF | Very rigid, stable | Abrasive, expensive | Hardened nozzle required |
🔀 Variants
- EDC Lightweight: 50% Gyroid, PETG, layer 0.20 mm → daily comfort
- Power Build: 100% Concentric, PA-CF, hardened nozzle → max rigidity
- Outdoor: ASA, extra grip texture, lanyard hole 4.5 mm
🔧 Functional Engineering Lab
Purpose-built 3D printed solutions.
✔ Tested on Bambu Lab platforms
✔ Tolerance-optimized geometry
✔ Print-efficiency focused
✔ AMS-compatible where applicable
Built to solve real problems.
🚀 If this model helped you, consider using a Boost.
Your support helps fund testing, prototyping and future functional designs.
— Functional Engineering Lab
Function before form.
Explore my profile for more functional tools,
Print & AMS upgrades and workflow solutions.
If this model improved your setup,
a Boost is always appreciated.
