IKEA Skadis pegboard accessories, specifically adapted for 3D printed pegboards (with smaller holes)

Ikea Skadis Pegboard - A collection of more compatible accessories

I installed a wall full of 3D printed pegboards

Then I was annoyed to find that most of the downloaded models didn't fit. This is because the hole sizes of printed pegboards are difficult to match the original Skadis

Actually, I also have an IKEA storage cabinet with a pegboard, and its hole width is not the Skadis size either, it's slightly smaller

In fact, controlling the slot width to 4.4mm provides better compatibility

For this, I plan to create a series of more compatible accessories, specifically tailored for 3D printed pegboards

Currently, there are a total of 11 plates of different accessories, and I will continue to update them

If you have any good suggestions for what accessories to make next, please feel free to leave a comment

Highly Recommended

Updated December 12 print profile 2 – lock for reinforcing Skadis pegboard accessories

I designed cracks to provide some compatibility in width. Please print a small quantity first, calibrate the tolerance, and then scale it to find the suitable ratio for you

Below is an introduction to print profile 1, continuously updated

plate 1 Hollow cylinders, inner diameter 55mm and 68mm

Perfectly compatible with WD40's 200ml and 360ml capacities

plate 2 Scissor holder

Fits medium and small scissors

plate 3 Pliers & needle-nose pliers holder

Fits the pliers and needle-nose pliers in the Bosch standard toolbox, can be used universally if other brands' sizes are not too different

plate 4 Flat hollow shelf 158mm, endlessly connectable

plate 5 Hanging storage boxes 78mm & 118mm & 158mm, endlessly connectable. 78mm fits mainstream tape measures

plate 6 Power drill bit and drill bit holder

plate 7 Caliper holder

plate 8 Standard hook, the most practical single item, can hang keys, hats, scissors, anything. The thickness is 4.4mm, you can scale the thickness according to your actual situation

plate 9 Adapter hook, used to adapt complex models with detachable hooks, such as

Garage Tool Collection

Clamshell Parts Box Storage

plate 10 Gravity hook, very convenient for hanging dishcloths

plate 11 Hollow square bins 55mm & 100mm

plate 12 Reinforced hook, very sturdy, can easily hold heavier objects
