15mm Shelf Phone Holder
Print Profile(1)
Description
This is a shelf phone holder, designed to fit perfectly on 15 mm thick surfaces.
The design is robust, functional, and 100% optimized for support-free printing, ensuring speed, material savings, and an excellent finish.
The front base accommodates phones of various sizes, designed with a 14 mm channel depth and ergonomic tilt for better screen viewing.
Main model measurements:
- Top shelf fitting: 15 mm
- Total part width: 60 mm
- Phone area depth: 14 mm
- Ergonomic tilt: 82°
- Main thicknesses: 4 mm
- Usable support height: approx. 82 mm
Ideal for:
✔ Home office
✔ Live streaming on phone
✔ Quick consultations at your desk
✔ Recordings
✔ Daily use on a shelf or bookcase
⭐ PRINT SETTINGS
- Technology: FDM
- Recommended material: PLA or PETG
- Layer height: 0.20 mm
- Nozzle: 0.4 mm
- Infill: 15% to 25%
- Supports: Not needed
- Walls: 2 to 3 lines
- Speed: standard (50–65 mm/s)
- Orientation: print standing up, as in the photo
- Approximate consumption: depends on cut height, but it is economical
- No post-processing needed
