<h2>Consigli di stampa (Bambu A1 mini • ugello 0.4 • PLA High Speed)</h2><ul><li>Profilo: 0.20mm Standard @ BBL A1M</li><li>Altezza layer: 0.20 mm (0.16 mm se vuoi più definizione sui denti/sopracciglia)</li><li>Larghezze linea (indicative, come in screen): default ~0.42 mm; primo layer 0.50 mm</li><li>Pareti: 3 perimetri (≈1.26 mm)</li><li>Top/Bottom: 5 top / 4 bottom</li><li>Riempimento: 12–15% (Grid o Gyroid)</li><li>Ventola: on (100% dal 3° layer per il PLA HS)</li><li>Temperature PLA HS: nozzle 215–225 °C • piano 55–60 °C (usa i preset del tuo PLA; io ho usato Generic PLA High Speed)</li><li>Seam/giunzione: allineata sul retro del frac (come da screen) per nasconderla</li><li>Adesione: Brim 4–6 linee consigliato (testa grande, piedi sottili = più stabilità)</li><li>Ritrazione e velocità: lascia i preset Bambu del profilo Standard (funzionano bene col PLA HS)</li></ul><h2>Orientamento &amp; supporti</h2><ul><li>Orientamento: stampa in piedi sulla base.</li><li>Supporti: Sì.<ul><li>Tipo: “Organic/Albero” (o Normali se preferisci)</li><li>Soglia: 55°</li><li>Densità: 12–15%</li><li>Interfaccia: attiva; distanza Z 0.20 mm</li><li>Aree che richiedono supporti: sotto il mento, mano alzata, estremità del papillon e lembi del frac.</li></ul></li><li>Evita supporti interni inutili: se usi “solo da piano di stampa” rimuovi tutto facile, zero gabbie dentro la testa.</li></ul>

<h2>Printing Tips (Bambu A1 mini • 0.4 nozzle • PLA High Speed)</h2><ul><li>Profile: 0.20mm Standard @ BBL A1M</li><li>Layer height: 0.20 mm (0.16 mm if you want more definition on teeth/eyebrows)</li><li>Line widths (indicative, as in screenshot): default ~0.42 mm; first layer 0.50 mm</li><li>Walls: 3 perimeters (≈1.26 mm)</li><li>Top/Bottom: 5 top / 4 bottom</li><li>Infill: 12–15% (Grid or Gyroid)</li><li>Fan: on (100% from 3rd layer for PLA HS)</li><li>PLA HS Temperatures: nozzle 215–225 °C • bed 55–60 °C (use your PLA's presets; I used Generic PLA High Speed)</li><li>Seam/joint: aligned on the back of the coattails (as in screenshot) to hide it</li><li>Adhesion: Brim 4–6 lines recommended (large head, thin feet = more stability)</li><li>Retraction and speed: leave the Bambu presets of the Standard profile (they work well with PLA HS)</li></ul><h2>Orientation &amp; Supports</h2><ul><li>Orientation: print upright on the base.</li><li>Supports: Yes.<ul><li>Type: “Organic/Tree” (or Normal if you prefer)</li><li>Threshold: 55°</li><li>Density: 12–15%</li><li>Interface: active; Z distance 0.20 mm</li><li>Areas requiring supports: under the chin, raised hand, ends of the bow tie, and coattails.</li></ul></li><li>Avoid unnecessary internal supports: if you use “only from print bed”, everything is easy to remove, no cages inside the head.</li></ul>

0.2mm layer, 2 walls, 15% infill

You shall not share, sub-license, sell, rent, host, transfer, or distribute in any way the digital or 3D printed versions of this object, nor any other derivative work of this object in its digital or physical format (including - but not limited to - remixes of this object, and hosting on other digital platforms). The objects may not be used without permission in any way whatsoever in which you charge money, or collect fees.

This user content is licensed under a Standard Digital File License.

“PoP Style” di Jack Skeletron in posa: Testa oversize, sopracciglia marcate, sorriso cucito, papillon a pipistrello e frac lungo. È pensata per essere stampata in un unico pezzo in verticale; i dettagli del volto e del colletto vengono fuori benissimo già a 0.20 mm.Fan art non ufficiale ispirata all’estetica “funko/chibi”. &nbsp;&nbsp;Solo per uso personale, non commerciale. Tutti i diritti dei personaggi originali restano dei rispettivi proprietari.<h2> </h2><h2>Consigli di stampa (Bambu A1 mini • ugello 0.4 • PLA High Speed)</h2><ul><li>Profilo: 0.20mm Standard @ BBL A1M</li><li>Altezza layer: 0.20 mm (0.16 mm se vuoi più definizione sui denti/sopracciglia)</li><li>Larghezze linea (indicative, come in screen): default ~0.42 mm; primo layer 0.50 mm</li><li>Pareti: 3 perimetri (≈1.26 mm)</li><li>Top/Bottom: 5 top / 4 bottom</li><li>Riempimento: 12–15% (Grid o Gyroid)</li><li>Ventola: on (100% dal 3° layer per il PLA HS)</li><li>Temperature PLA HS: nozzle 215–225 °C • piano 55–60 °C (usa i preset del tuo PLA; io ho usato Generic PLA High Speed)</li><li>Seam/giunzione: allineata sul retro del frac (come da screen) per nasconderla</li><li>Adesione: Brim 4–6 linee consigliato (testa grande, piedi sottili = più stabilità)</li><li>Ritrazione e velocità: lascia i preset Bambu del profilo Standard (funzionano bene col PLA HS)</li></ul><h2>Orientamento &amp; supporti</h2><ul><li>Orientamento: stampa in piedi sulla base.</li><li>Supporti: Sì.<ul><li>Tipo: “Organic/Albero” (o Normali se preferisci)</li><li>Soglia: 55°</li><li>Densità: 12–15%</li><li>Interfaccia: attiva; distanza Z 0.20 mm</li><li>Aree che richiedono supporti: sotto il mento, mano alzata, estremità del papillon e lembi del frac.</li></ul></li><li>Evita supporti interni inutili: se usi “solo da piano di stampa” rimuovi tutto facile, zero gabbie dentro la testa.</li></ul><h2>Scala &amp; dimensioni</h2><ul><li>Il modello è pensato per la classica scala “pop” (10–12 cm circa a 100%).</li></ul><h2>Licenza</h2>Fan art condivisa per uso personale. No vendita/redistribuzione dei file.

“PoP Style” Jack Skellington in pose: Oversize head, prominent eyebrows, stitched smile, bat bow tie, and long coattails. It is designed to be printed in a single piece vertically; the details of the face and collar come out great even at 0.20 mm.Unofficial fan art inspired by “funko/chibi” aesthetics. &nbsp;&nbsp;For personal use only, not commercial. All rights to the original characters remain with their respective owners.<h2> </h2><h2>Printing Tips (Bambu A1 mini • 0.4 nozzle • PLA High Speed)</h2><ul><li>Profile: 0.20mm Standard @ BBL A1M</li><li>Layer height: 0.20 mm (0.16 mm if you want more definition on teeth/eyebrows)</li><li>Line widths (indicative, as in screenshot): default ~0.42 mm; first layer 0.50 mm</li><li>Walls: 3 perimeters (≈1.26 mm)</li><li>Top/Bottom: 5 top / 4 bottom</li><li>Infill: 12–15% (Grid or Gyroid)</li><li>Fan: on (100% from 3rd layer for PLA HS)</li><li>PLA HS Temperatures: nozzle 215–225 °C • bed 55–60 °C (use your PLA's presets; I used Generic PLA High Speed)</li><li>Seam/joint: aligned on the back of the coattails (as in screenshot) to hide it</li><li>Adhesion: Brim 4–6 lines recommended (large head, thin feet = more stability)</li><li>Retraction and speed: leave the Bambu presets of the Standard profile (they work well with PLA HS)</li></ul><h2>Orientation &amp; Supports</h2><ul><li>Orientation: print upright on the base.</li><li>Supports: Yes.<ul><li>Type: “Organic/Tree” (or Normal if you prefer)</li><li>Threshold: 55°</li><li>Density: 12–15%</li><li>Interface: active; Z distance 0.20 mm</li><li>Areas requiring supports: under the chin, raised hand, ends of the bow tie, and coattails.</li></ul></li><li>Avoid unnecessary internal supports: if you use “only from print bed”, everything is easy to remove, no cages inside the head.</li></ul><h2>Scale &amp; Dimensions</h2><ul><li>The model is designed for the classic “pop” scale (approx. 10–12 cm at 100%).</li></ul><h2>License</h2>Fan art shared for personal use. No sale/redistribution of files.
