Glock 17/19 + TLR-7 Light OWB Holster w/ Optic Cut

  Similar to the Glock 17/19 Holster I already have published, this is the same, but for those models of handguns with a TLR-7 Streamlight attached.  The holster has a Safariland bolt pattern to be attached to all compatible platforms.  This includes my parametric holster hanger setup that I also already have published.

  There are four profiles.

G17 Right Handed

G17 Left Handed

G19 Right Handed

G19 Left Handed

  These should also work for most Glocks that use doublestack magazines and Glock Clones.  This design was tested around a Glock 17 and a Ruger RXM both, so it should work for Springfield Echelons and PSA Daggers as well.

  To assemble, use #8-32 hardware, same as Safariland.  Lengths will vary depending on what you are mounting the holster to.  The holster is designed for you to be able to press the appropriate nut into the recess, and be held there.  You will need:

3x regular #8-32 nuts

1x nylock #8-32 nut.  This is for the tension.

3x #8-32 screws, either hex, button head, whatever.  This depends on what you are attaching to.

1x martini or button head #8-32 screw.  This is for the tension.

  To assemble, press the 3 regular nuts into the recesses inside the holster.  You can then use the 3 screws to attach the holster to whatever.  Be sure that the lengths are correct, so that the threads of the screws are not extending into the holster and inhibiting your gun or scratching it.  Take the remaining nylock nut and martini screw.  Press the nut into the hex recess of the tensioner and thread the screw in.  It's best for you to place the unloaded handgun and light into the holster and tension until desired tightness is achieved.

  Print in PETG for best results in outdoor work.

  Roadmap for the future is to convert this design into an IWB EDC. That'll have to be done in the next few weeks.  I'd eventually like to get my hands on a TLR-1 for this, but I don't know when that will be.  However, the IWB is coming soon.  Thanks for all the support.  Feel free to offer comments, critique, etc.

UPDATE 10/21/25: IWB G19/17 with Streamlight TLR-7 or Surefire XC3 now available!  Available here: https://makerworld.com/en/models/1911454-glock-17-19-ruger-rxm-w-tlr-7-light-iwb-holster#profileId-2049774

1/22/2026 UPDATE:

By popular request, a Belt Mount system is now available for Safariland bolt patterned holsters, including this one.
