Printable IdZ stock for VFC G36

A Fully printable* IdZ style stock for the g36 platform.  Comes with all the pieces necessary (except the screws/pins and springs), designed with 3d printing in mind, while attempting to replicate the originals function as close as possible.

You will also need:

   -2x M3-0.5 x 4mm button head cap screws (retainer latch)

   -1x 0.4 x 5 x 30mm spring (dowel Pin)

          - A 0.3 x 4 x 30mm spring can be added into the previous spring for more tension if necessary*

   -2x M3 x 25mm Roll pin (Cheek riser & buttpad)

   -1x M3 x 16mm Roll pin (LoP latch + dowel pin joint)

   -1x M2.5 x 16mm roll pin (Buttons

        - A m3 x 16mm roll pin can be used in place of this one, but it may make disassembly/assembly difficult.



Here is the guide for assembly if needed:

          https://docs.google.com/document/d/1unaHPdnaJAYubtcVjzyb1dGbRrr1WoCQ4emuq5OC6o0/edit?usp=sharing

There are some QoL features missing (No lockup when folded, doesn't adjust LoP in the way many stocks do etc.) that I may or may not go back and fix later.  It is working though, and the material you put in it is what you'll get out of it.

Convex style buttpad will be added later (There is an stl in the 3mf file that is usable but not fine tuned.  play at your own risk).

I HIGHLY recommend you use the settings provided, using pa6-cf as a minimum.
              The Dowel pin MUST be printed in either a fiber nylon or PPS-cf material AND must be printed sideways.  Anything less rigid may not hold up to the shear forces, and will easily snap.


*Amazon link to screws/springs/pins are here.

Springs: https://www.amazon.com/dp/B0BVTDP29W?th=1
Roll pins: https://www.amazon.com/dp/B0D637BXG1?th=1  *MAKE SURE THEY ARE METRIC*

Screws: https://www.amazon.com/dp/B0DP4XKFXD?th=1
