X Wing Drone

luisengineering
Hobby & DIY>RC
IP Report

Print Profile(1)

All
P1S
H2D Pro
H2S
X1 Carbon
X1
P1P
H2D
A1
X1E
P2S
H2C
X2D
A2L
0.2mm layer, 2 walls, 15% infill
0.2mm layer, 2 walls, 15% infill
Designer
8.4 h
4 plates
5.0(6)
Open in Bambu Studio
Boost
798
1550
52
56
723
77
Released

Description

Content has been automatically translated.
Show original

Parts List:

FC ESC Combo: https://www.fpv24.com/de/speedy-bee/speedybee-f405-v4-bls-55a-30x30-stack

Battery 1300 mAh: https://www.fpv24.com/de/tattu/tattu-r-line-v40-lipo-akku-130c-xt60-1300mah-6s

Flight controller: https://www.fpv24.com/de/speedy-bee/speedybee-f7-v3-bl32-50a-30x30-stack-fpv-fc-flight-controller-esc

Motors: https://www.fpv24.com/de/iflight/iflight-xing-2306-2450kv-4s-unibell-camo-racing-motor

GPS: https://www.banggood.com/custlink/GGKi2Ic35O

4 inch Propeller: https://www.fpv24.com/de/gemfan/gemfan-4052-4x52-flash-3-blatt-propeller-lila-2xcw-2xccw

4 inch Propeller: https://www.fpv24.com/de/hqprop/hq-durable-dreiblatt-propeller-d4x53-grau-4-stueck-4-zoll

Air Unit: https://www.fpv24.com/de/dji/dji-o4-air-unit-fpv-lufteinheit

Servo: https://amzn.to/3Up9sP0

drone
star wars
x wing

Comment & Rating (52)

(0/1000)
@3DBoss1
how much does it cost 💲 to make
3
Reply
@Moritz_GBW
I asked an AI, if you use PC(polycarbonat), wich is very Hard and Only not resistant to UV, it would Cost you something about 10€, what is about 11$.
0
Reply
@3DBoss1
Replying to @Moritz_GBW :
I meant the hardware
0
Reply
@h2downer
You have a brain? Search it up?
0
Reply
@Reste1964
Print Profile
0.2mm layer, 2 walls, 15% infill
Nice job! I’ll try to prepare my X-Wing asap! Thanks!
0
Reply
@kibbycabbit
Ohh you chose to print plate instead of carbon cutout? How well does it fly? I swear carbon frame is necessary for rigid and stiff?
(Edited)
1
Reply
@Reste1964
Replying to @kibbycabbit :
This is only for an assembly test. When I’ll be sure that all components fit in place, I’ll surely cut the frame in carbon fiber!
0
Reply
@s_vacek
My x-wing, still in the assembly phase. I would like to know how your flight modes are set? Do you have ANGLE set for takeoff and AIRMODE for flight?
0
Reply
@user_2931704617
obviously air
0
Reply
@user_1696327269
i managed so far...
(Edited)
0
Reply
@user_3580389778
There is no video clip of the first fight test, sir. Thank you very much.
The designer has replied
1
Reply
@luisengineering
The Video will be live at 12:00 on YouTube today. But you can find clips of it flying on my instagram already.
1
Reply
@radish5
Replying to @luisengineering :
Could you add a link to the YouTube video please?
0
Reply
@crewkoFPV
Is the 2306.5 motor suitable?
2
Reply
@schnippo
Boosted
Mega awesome. Respect. Awesome work!
Show original
2
Reply
@user_1501416939
Hello what is the YouTube video link Thank you
Show original
0
Reply
@Lexer
https://youtu.be/NnZrP3g4y2g?si=oTlfJ4f4lS6u5XHg
2
Reply
@tremendaiguana
im so amazed that it actually flies
0
Reply
@Bluesonicboom18
Does it even work? or does it just look like the nose of the plane is always up and it hovers
The designer has replied
0
Reply
@luisengineering
Yessss. it goes up to 216 kp/h. YouTube Video will follow soon. Clips are on instagram already Name: luisengineering
0
Reply
@kibbycabbit
Use servo to tilt camera down and up. When launching or landing, flip a switch on your transmitter and camera will adjust tilt and you can land/launch without taking off goggles.
0
Reply
@crewkoFPV
How much does this drone weigh?
1
Reply
