Description
Based on the original design, the transmission method, front and rear wheel connection, and steering have been optimized and adjusted
Your valuable feedback is welcome Here are some points to note if you print it yourself
1 Some parts may require sanding for proper fit during installation
2 The front and rear wheels use bearings with an inner diameter of 5 and an outer diameter of 8 The motor used is a 370 with an outer diameter of 24 and costs 3 yuan
3 It is recommended to connect the external parts to the chassis with screws for easy replacement in case of collision damage
4 The tire tread in the picture has added a sealing ring to increase anti-slip
5 The servo mount is glued Make sure to use a receiver remote control that can select adjustable neutral position and limited servo travel
6 Do not go too fast because I have already crashed several
7 Debug thoroughly before putting it on the ground
