Description

project: gustave final.hfp
Print at 100% infill with a layer height of 0.04mm with a base layer of 0.2mm

The Model is 162.03x233mm in size
You may print at higher layer heights below the Base Thickness of 0.6mm
The Max allowed Thickness is 3mm and the Actual Thickness is 2.36mm

Filaments Used:
    PLA BambuLab Matte Charcoal Transmission Distance: 0.1
    PLA BambuLab Basic Indigo Purple Transmission Distance: 0.8
    PLA PolyLite Natural Transmission Distance: 34
    PLA BambuLab Basic Gold Transmission Distance: 2.8
    PLA BambuLab Matte Ivory White Transmission Distance: 3.4
This print uses 5 unique filaments

Swap Instructions:
    Start with Charcoal
    At layer #12 (0.64mm) swap to Indigo Purple
    At layer #14 (0.72mm) swap to Natural
    At layer #18 (0.88mm) swap to Charcoal
    At layer #20 (0.96mm) swap to Natural
    At layer #42 (1.84mm) swap to Gold
    At layer #49 (2.12mm) swap to Ivory White for the rest.

3mf has a height range modifier to save some print time.
