Rack Mount for Reolink RLN8-410 NVR with tray
IP Report
Print Profile(1)
0.2mm layer, 3 walls, 20% infill
Designer
7.4 h
1 plate
Open in Bambu Studio
Boost
27
115
7
4
174
77
Released
Bill of Materials
Maker's Supply Kits and Parts
Select all
Description
Mount designed for the Reolink RLN8-410 NVR, compatible with standard 19" racks and intended to occupy 1U of rack space. The NVR is slightly taller than 1U, so it’s recommended to leave some clearance underneath for better installation.
I designed this mount for my rack, which is very shallow, allowing the NVR to be installed securely and neatly even in limited spaces.
The design also includes an additional tray that can be used to hold small accessories or extra devices.
The mount can be fixed by replacing the original case screws with longer M3 screws.
Warning: do not exceed 10/12 mm in length, especially near the power supply, to avoid damaging the internal PCB.
