Typhoon 2000 EF2000 64MM EDF
Print Profile(0)
Description
Materials:
One main carbon rod, 6mm diameter, less than 390mm in length
Aileron and tail-mounted articulated carbon rods, 1.8mm diameter, 100cm length, cut as needed (If using filament, frequent inspection is recommended)
Four 5mm diameter, 2mm thick cylindrical magnets
Two to three 9g servos (13g metal servos recommended), two to three 30cm servo extension cables
FMS 64mm ducted fan; 4S battery recommended for 3S version
Recommended center of gravity: shift 15mm rearward from the marked point on the underside of the wing
Recommended flow rate for ABS/ASA: 0.875
Printed parts weight: 600-650g, approximate takeoff weight: 1100g
