Satisfactory Power Shard lamp

This is a model of a power shard from the game Satisfactory.

Warning: This model requires electrical knowledge as a mains bulb its used in its design, Only Emulate this aspect if you are a skilled professional. The elements that hold the bulb can be altered to hold a low voltage alternative.

Final Dimensions:

565mm Tall

220mm Wide (Diameter)

Printing List:

base plate claws X2 (Grey)

black filler plate bulb X1 (Black)

black filler plate X1 (Black)

bottom grey puck X1 (Grey)

top grey puck X1 (Grey)

fake rivet head X16 (Grey)

gem lower X1 (Clear)

gem upper X1 (Clear)

grill ring X2 (Black)

main section orange bottom X2 (Orange)

main section orange top X2 (Orange)

main top cap black lower X2 (Black)

main top cap black upper X2 (Black)

rod sleeve X10 (Grey)

rod X5 (Black)

Additional Materials:

E14 Bulb Holder Light Socket (https://www.amazon.co.uk/dp/B0BFJ3QNFQ?ref_=ppx_hzsearch_conn_dt_b_fed_asin_title_1)

E14 Bulb (I used Philips Hue candle Bulb)

M5 Threaded rod X4 (About 390mm per rod)

M5 Bolt (Black) X10 (20mm) (For the claw sections)

M5 Bolt (Black) X10 (12mm) (For black filler plate)

M5 Bolt X10 (35mm) (For securing black cap top and bottom to grey puck)

M5 Bolt X10 (25mm) (For securing main section orange top and bottom to grey puck)

M5 Threaded inserts X40 (6mm deep, 7mm Diameter)

Switch (https://www.amazon.co.uk/dp/B01MQPWR46?ref_=ppx_hzsearch_conn_dt_b_fed_asin_title_18)

3 Meters wire (https://www.amazon.co.uk/dp/B07M7TDVPY?ref_=ppx_hzsearch_conn_dt_b_fed_asin_title_20)

Plug End (https://www.amazon.co.uk/dp/B0B3QNCCC8?ref_=ppx_hzsearch_conn_dt_b_fed_asin_title_17)

Some other materials may be needed as I cant remembers all of the internal components.

Tips:

The wire for the bulb is ran up one of the rods, only 4 have rods in

For the Gem use a circular infill pattern as it makes it clearer

DO NOT use a bulb that gets hot, use LED

Most parts have been split into multiple as to not need support

Happy Printing!
