MISSILE TURRET TOY

This is a model that builds further upon the mechanism I created in my mini toy gun. see here:

https://makerworld.com/en/models/1262350-little-toy-gun#profileId-1287256

if you like this model, please give me a boost :)

BUILDING INSTRUCTIONS (VIDEO):

watch here: https://youtube.com/shorts/jNTV7feTENw?si=KzD6uiffGKNp_Xry

BUILDING INSTRUCTIONS (PHOTOS):

take the base and insert the worm gear. At the end you might have to push a bit to make sure it clicks into place.

take the gear and place it between the two holes. Make sure the cut outs in the gear and the base are aligned:

insert the axle. The tooth on the axle should slide inside the cut outs (or you wont be able to insert the piece)

now rotate the long worm gear untill the tooth on the axle are horizontally oriented:

place the pusher in the barrel:

put a rubber band from the bambu beginners kit around the front of the red part and the little tower on the yellow part:

repeat this for all the barrels (12x):

notice that some barrels are the mirror of the others. This is important because they should go in the correct location in the 2 barrel holders:

now click all the barrels inside the barrel holders:

the end result should look like this

now take the base part with the gears and hold the 2 barrel holders like this:

push the barrel holders on the axle and rotate the two barrel holders so they face upward

rotate the wheel on the back to rotate the barrel holders:

insert the missiles:

done! have fun:
