Variously sized angle joints for constructions, gazebos, and tubular structures. I used them to build a cube with tubes for school.

Reinforced joint, requiring sanding post-print, durable with a through-hole for optional wood screws or pins for locking.

Dimensions in the print profiles: ODA-00017-A-R00 = ASSEMBLY WITH ALL JOINTS

LONG JOINT FOR D=22 TUBE
SHORT JOINT FOR D=22 TUBE
SHORT JOINT FOR D=20 TUBE
SHORT JOINT FOR D=25 TUBE

135°-90° LONG JOINT FOR D=16 TUBE

135°-90° LONG JOINT FOR D=17 TUBE

Should you require customized profiles, I can share the dimensions you request.
