Nobodyknows I. HueForge
Print Profile(1)
Description
Picture source Pinterest: Alpacat
Then used HueForge v0.8.1 to create the model.
Print at 100% infill with a layer height of 0.08mm with a base layer of 0.16mm.
I made two version size the .stl file. In the printing profile is used 150x150 (for A1Mini) and the second is bigger 200x200 mm. The color change settings are identical.
Or you can only modify the X and Y dimensions. Do not adjust the height (Z) in your slicer! The layers would not be correct. You may print at higher layer heights below the Min Depth of 0.48mm. The Max Depth is 2.2mm and the Actual Depth is 2.2mm.
It is possible to print without AMS by manually changing the filament (setting filament change or pause) in the slicer, depending on your printer and sw support.
Filaments Used:
PLA Elegoo + Black Transmission Distance: 0.3
PLA Sunlu META Grey Transmission Distance: 3.6
PLA BambuLab Basic Orange Transmission Distance: 4.8
PLA Elegoo + White Transmission Distance: 6
This print uses 4 unique filaments
Swap Instructions:
Start with Black
At layer #10 (0.88mm) swap to Grey
At layer #14 (1.2mm) swap to Orange
At layer #15 (1.28mm) swap to White for the rest.
Share your prints, and…
Boost Me (for free)
Thank you!
License
You shall not share, sub-license, sell, rent, host, transfer, or distribute in any way the digital or 3D printed versions of this object, nor any other derivative work of this object in its digital or physical format (including - but not limited to - remixes of this object, and hosting on other digital platforms). The objects may not be used without permission in any way whatsoever in which you charge money, or collect fees.
