Pocket Fidget Bolt (print in place, 9g , 40 min)
Print Profile(2)
Description
New update, added texture on nut sides
This is my second print in place fidget bolt toy (here is the first one). The main difference from the first one I did is the size and that gravity isn't enough turn the nut, you always need to use your finger to make the nut rotate.
I find this version more convenient to carry around in my pocket and it is very quiet compared to my first bolt.
Print instructions:
Designed for 0.4 nozzle, 0.2 layer height, PLA & PLA Silk filaments
Provided print profile already have correct settings, but if you are using different slicer, here are the recommended settings:
- 0.2 layer height
- 0% infill
- 3 layers for top and bottom shell
- concentric solid infill pattern
- 2 walls for the bolt itself
- 10 walls for the nut (you have to add modifiers to the nut only, or just set ten walls for everything)
License
You shall not share, sub-license, sell, rent, host, transfer, or distribute in any way the digital or 3D printed versions of this object, nor any other derivative work of this object in its digital or physical format (including - but not limited to - remixes of this object, and hosting on other digital platforms). The objects may not be used without permission in any way whatsoever in which you charge money, or collect fees.
