Multi Pen and Pencil holder for Book or Notebook

A fully customizable holder for 1 to 3 pens or pencils for a book or notebook.

You could configure the holder to support, 1, 2 or 3 pen/pencils, each one can have diferente diameters and you can add a personalized text if you want.


This design is parametric, so every feature mentioned can be customized, by simply clicking "Customize" in this page.


Set of features that you can customize (all measurements are in mm):

• Holder Width (Total Width)
• Holder Height (Total height)
• Holder Thickness (Increase to get more strength at cost of a bulkier holder)
• Holder Radius (Left round corners)
• Clip Width (Increase to have a bigger clip flap in the back)
• Clip Gap Right (Increase to use the holder in a bulkier cover or to clip multiple pages at once)
• Clip Gap Left (Less gap = more grip, but pay attention to the Gap Right, if you increase the Right you should also increase the Left)
• Remove Clip (If want just the front of the holder, removing the entire clip)
• Support Height (Height for pen or pencil support, should be ≤ than Holder Height)
• Support Offset (Horizontal placement for the pen support, measure from right margin of holder)
• Support Thickness (Thicker support = less flexible support and more grip to pen or pencil)
• Support Gap (Gap between support walls, bigger gap = less grip)
• Support Orientation (Select Vertical to use the holder on the side of book and Horizontal to use at top of book)
• Support Number (You can configure the holder to have 1, 2 or 3 pen/pencil supports)
• Support Diameter 1 (Adapt according to the pen or pencil you will be using)
• Support Diameter 2 (Adapt according to the pen or pencil you will be using)
• Support Diameter 3 (Adapt according to the pen or pencil you will be using)
• Text Enable (If you want some text on left of pen or pencil support)
• Text Size (Font height, use in conjunction with Support Offset and/or Holder Width so all the text can be displayed)
• Text Depth (Bigger value means the text is more visible, if you define Holder Thickness to 1.5 and this to 1.5, each letter will become a hole.
• Text Personalized (Free text to display in the holder)

IMPORTANT - If the pen/pencil support/s disappear while you are customizing its because you need to increase Holder Height and/or decrease Support Number and/or Support Diameter.

I recommend to maintain Face Detail set to 100 but you can lower for test purposes and generating the 3d rendering when editing the parameters.

*in the files folder you can download 3 versions for 1 to 3 pens/pencils, with the default values, and without any text or branding.

** Changelog
// V1.0 - Init version
// V1.1 - Added pen support orientation option, personalized gap option
// V2.0 - Added multi-pen support (up to 3)
// V3.0 - Added multi diameter support
// V3.1 - clip_gap_right min value changed to 0.2 allow a tight fit for the clip as requested by user @fleetscut

// V4.0 - Option to remove Clip as requested by user @AnthonyC99 | Object rotation when Horizontal support is selected | Min Support offset if now 0
// V4.1 - Min holder_width to 20 and min clip_width to 15 as requested by user @AnthonyC99
