Collapsing Candy Cane

Search models, users, collections, and posts

Drewski_09

Toys & Games>Other Toys & Games

IP Report

Print Profile(3)

All

A1 mini

P1S

P1P

X1 Carbon

X1E

H2D

H2D Pro

H2S

P2S

H2C

X2D

A2L

0.2mm layer, 2 walls, 15% infill

Designer

7.5 h

2 plates

4.5(26)

0.16mm layer, 2 walls, 15% infill

Designer

12.9 h

2 plates

5.0(6)

(AMS)0.2mm layer, 2 walls, 15% infill

Designer

33 h

1 plate

4.5(2)

Open in Bambu Studio

Boost

442

834

631

289

Released

Description

***AMS VERSION ADDED***(11/19/24)***

The only thing that needs glued is the hook onto the handle.

Original

This is a Collapsing Candy Cane. Designed onto two plates, white and red, and to be glued together after printing. I would rather assemble a few parts rather then waste 75% more filament then what the model actually uses, and for those who do not have AMS

All parts are named inside of slicer.

Settings:

Hook pieces have normal(auto) at 35
Handle pieces have Tree(manual) painted on the under side of the coils
Blade pieces have brim.

Assembly:

Put white and red hook together and glue along edges.
Glue inside of one handle coil and slide onto tube.
Put glue on exposed portion of tube and spin the other handle coil onto tube.
1. Be sure to align both ends.
Assemble blade pieces largest to smallest.
Slide blade assembly into tube assembly.
Glue hook assembly into the larger opening on tube assembly. (Same side blades went in)
1. Use quite a bit of glue of this step!
Let dry and have fun!!!
