LED Lamp 001, Wireless, Rechargeable, Dimmable

This LED lamp project offer a remix of the original design with a Wireless, Rechargeable, Dimmable cheap led.

Recommended filaments: Bambu PLA Basic Jade White

https://store.bambulab.com/products/pla-basic-filament?variant=40820833517683

Hardware Kit:

1-smaller and soft led: (see relative plate 1)

tested with: https://www.amazon.it/dp/B0CCDLVC4N

there is some lamp on ali, but you need to find some with dimension 80x20mm.(3d part internal diameter is 80.8)

OR

2-medium and stronger led, dimmable(see relative plate 2):

https://it.aliexpress.com/item/1005007113037228.html#nav-specification

lamp dimension: 85x20mm (3d part internal diameter is 85.4)

OR

3-bigger and stronger led, dimmable(see relative plate 2):

https://a.aliexpress.com/_Ex505Jj

lamp dimension: 86x20mm (3d part internal diameter is 86.4)

Please make sure you clean the build plate before printing and/or applying glue to prevent print failures.

Instructions:

1-print the three parts. (choose between the 2nd and 3th plate if you want soft or strong dimmable led)

2-glue the smaller parts together

3-insert a led into the glued part (no need any glue here)
