Simple Riser Leg

This is my first uploaded model

You need to prepare a wooden board. The board should be 12mm thick, 200mm wide, and its length is not limited. If using risers, it is not recommended to exceed 50cm, and if not using risers, it is also not recommended to exceed 70cm. Although this model is already very sturdy, to be safe, avoid placing overly heavy or fragile items (disclaimer)

I have reserved a screw hole on the side. If you feel it's not secure enough, you can use a screw to fix the wooden board (it's actually very stable even without screws)

After printing, simply insert it, with almost no assembly difficulty. When inserting the risers, it is recommended to align the bottom surface of the bracket with the bottom surface of the riser, this will look better. Additionally, there is a clasp on each side of the riser, please be careful not to install them backward

The model will have a little support, which can be easily removed with needle-nose pliers. I have printed three plates without any issues

Because the model is large, please make sure to clean the build plate when printing, and properly enclose the printer to prevent warping/printing failures for large models

It is recommended to print with PETG, and the print profile is also for PETG. Sufficient clearance has been left for PETG. If you use PLA, there is a high possibility of excessive clearance, requiring manual adjustment of the clearance

If you find any issues or need to adapt it for other machines, I have also provided the source files, which can be directly opened using SolidWorks. If you have modeling skills, you can modify the model directly

Thank you for your support
