Cell Vegetables

Print Profile(1)

All
A1
P1P
P2S
H2C
P1S
A1 mini
H2D
H2D Pro
H2S
X1
X2D
X1 Carbon
X1E
A2L

0.08mm layer, 3 walls, 5% infill
0.08mm layer, 3 walls, 5% infill
Designer
2.7 h
1 plate

Open in Bambu Studio
Boost
2
4
0
0
7
3
Released

Description

 📋 MODEL DATA
════════════════════════════════════════════════════
 Model Name.................. Objects/object_1


════════════════════════════════════════════════════
 🖨️ PRINTER
════════════════════════════════════════════════════
 Model....................... Bambu Lab A1
 Nozzle Diameter............. 0.4 mm
 Nozzle Type................. Acero Inoxidable
 Kinematics.................. i3
 Build Volume................ 256×256×256 mm
 Bed Type.................... Textured PEI Plate

════════════════════════════════════════════════════
 ⚙️ PRINT PROCESS
════════════════════════════════════════════════════
 ────────────────────────────────────────────────
 LAYERS
 ────────────────────────────────────────────────
 Layer Height................ 0.08 mm
 First Layer Height.......... 0.2 mm
 Top Layers.................. 9
 Bottom Layers............... 7
 Adaptive Layer Height....... No
 Vase Mode (Spiral).......... No

 ────────────────────────────────────────────────
 WALLS
 ────────────────────────────────────────────────
 Wall Loops.................. 3
 Line Width.................. 0.42 mm
 Wall Generator.............. Classic
 Seam Position............... Back
 Elephant Foot Comp.......... 0.075 mm
 Brim Width.................. 5 mm

 ────────────────────────────────────────────────
 IRONING
 ────────────────────────────────────────────────
 Ironing Type................ No Ironing
 Pattern..................... zig-zag
 Speed....................... 30 mm/s
 Flow........................ 8 %
 Line Spacing................ 0.15 mm

 ────────────────────────────────────────────────
 INFILL
 ────────────────────────────────────────────────
 Density..................... 5 %
 Pattern..................... Lightning

 ────────────────────────────────────────────────
 SPEEDS (mm/s)
 ────────────────────────────────────────────────
 Outer Wall.................. 200
 Inner Wall.................. 350
 Infill...................... 450
 Top Surface................. 200
 Bridge...................... 50
 Travel...................... 700
 First Layer................. 50
 Support..................... 150

 ────────────────────────────────────────────────
 ACCELERATION (mm/s²)
 ────────────────────────────────────────────────
 Default..................... 6000
 Travel...................... 10000

 ────────────────────────────────────────────────
 SUPPORTS
 ────────────────────────────────────────────────
 Enabled..................... Yes
 Type........................ Tree (Auto)
 Threshold Angle............. 15 °
 Top Z Distance.............. 0.08 mm
