TRÅDFRI lysdæmper til FUGA vægkontakt

Convert an IKEA TRÅDFRI ON/OFF button to resemble a FUGA IHC Wireless wall switch No soldering necessary

Parts you will need

1 x Insert, choose between 4 different battery types
1 x Button adapter
1 x TRÅDFRI dimmer (70408595) or curtain button (cannot be purchased separately)
1 x IHC Wireless button (5703302132305)
1 x Cover for low voltage push button (5703302132152)

How to print it

Layer height: 02 mm (alternatively 01 or 005)
Filament: Fiberlogy EASY PET-G 175 mm - Light Gray
Printer: Prusa i3 MK3S

Credits

Kasper Christensen: Overall Idea PCB placement
Michael Gylling Hviids: Securing the PCB in place Design of the button adapter

Michael's button adapter has been reused with a few modifications

Legal

Remember that the license (CC BY-NC-SA 40) does not permit commercial use You are therefore not allowed to sell the print for profit

The low voltage push button must not be mixed with 230V The intention is for it to be mounted directly on a wall, or in a box without 230V If you wish to remove a 230V switch and install the low voltage push button instead, you must seek help from a licensed electrician

This project is not endorsed by the companies whose products are modified

• LK FUGA® is owned by SCHNEIDER ELECTRIC DANMARK A/S
• TRÅDFRI is owned by IKEA of Sweden AB
• ZigBee is owned by ZigBee Alliance
