Parametric ToolBox

Please check your model to make sure it's working properly before printing.

With this parametric toolbox model file, you can quickly create a box with the desired width, depth, and height.

The strength of the box hinge areas as the box size increases has not been tested.

This depends on your experience, and your feedback is highly appreciated.
Your feedback will be highly appreciated.

Currently, boxes are created using four basic parameters:

Box Width,

Box Depth,

Box Height,

Cover Height.  (I recommend not more than half the height)

After downloading the 3mf or stl file, separate the model into objects with the splite to objects option in bambu studio.

Parts required for assembly;

--------------------------------------------

M3x30 4 pieces (not need nuts)

M3x40 2 pieces (for handle and locker parts axis)

update notes:

-------------------------

----12/10/2025

- Models explodes problems solved, (Make sure the model is healthy.)

- Width & depth size limit extended to 500mm.

- Add parametric handle
