150x100mm Frame 0.2mm layer, 3 walls, 7% infill

Designer

1.3 h

1 plate

100x150 with 2 hangers

Designer

1.3 h

1 plate

Boost

133

Released

Description

I sized two frames for the files that I'm building with the kids.

They are friction fit, just put the bottom of your hueforge print into the groove and then push the top of the print into place, and you will hear a “click”. You can remove the print the same way, by applying force to the top edge of the print.

Currently all of my uploads are between 2.24mm and 2.96 and these will work for all of them that are sized in either 150x100 or 100x100 dimensions.

Currently holds:

100x100

100x150 - Updated a print profile so you can use the frame as 100x150 or 150x100 (landscape or portrait)

150x150

I have built a 200x200 Friction Fit Frame as well now
https://makerworld.com/en/models/381229#profileId-281475

You could resize other hueforge to fit in these as well.

Comment & Rating (16)

@Vigo3D

Print Profile

All Frames - Separate Plates

Yes! Great! Next time I try this with a funky sparking plate from Ali! Thank you :)

The designer has replied

@CanadianGamer

oh please share if you reprint with that plate! I don’t have one but I was thinking about ordering one!!

(Edited)

@Vigo3D

Replying to @CanadianGamer :

I will do it maybe tomorrow when I print your cute Terrier ❤️ You should really buy this plate. I use it at 55° like the PEI plate.

(Edited)

@CanadianGamer

Replying to @Vigo3D :

I look forward to it. Think I'm going to get one of those plates on order from Ali as well!

(Edited)

@Mace3D

Print Profile

All Frames - Separate Plates

Great print!

The designer has replied

@CanadianGamer

Thanks for rating and sharing a picture! Looks Great!

@Mace3D

Like the design, but because it's not symmetrical, scaling to larger size isn't easy to do. Could you make a 150x150 frame?

(Edited)

The designer has replied

@CanadianGamer

yes you’re right, it doesn’t scale simply for additional size due to the way the friction fit works. I’ll upload a 150x150 today, I’ll need to build it instead of simply scaling it

@Mace3D

Replying to @CanadianGamer :

Thanks in advance!

@CanadianGamer

Replying to @Mace3D :

The 150x150 frame was just uploaded to the frame collection: https://makerworld.com/en/models/173529#profileId-190705 The main print profile now has all three options on different plates. Please let me know if there is any issues. I had to go through a few iterations to get it to fit right, but I only had one 150x150 to test with currently.
