Description
This is not my original work,
it's a remix of it to make it printable on 180mm plates, to connect themyou can use superglue and some pla melting it with the soldering Iron
You need some assorted 6-32 screws for the Front and back parts, power supply and reservoir. 6-32 1 3/4 in. screws for the fans and radiators. M3 screws to put things together. Use acrylamide and kicker on the threads if M3 screws don't hold. M3 heat inserts and M3 screws for the Mobo. Mobo sits on 5.5 mm tall printed spacers (glue on after putting in the heat inserts).
Soon an updated image with the components
I don't take any credit of the design/work, the creator of it is Empiricus on printables
