Mechanical Flux Dispenser 3cc

I designed this dispenser for a 3cc syringe. It is more convenient to dose solder paste from small syringes, since its viscosity is very high and it is squeezed worse in a large syringe and has inertia for extrusion. This effect is much lower with the use of small syringe capacities.

You can use a standard* syringe adapter, in the previous ones I showed how I did it, but you can also print it, as in this case.

See Also: Electric Flux Dispenser , Mechanical Flux Dispenser 5cc , Old Dispenser 10cc , Flux Dispenser Magnetic Cap

See the video for details:

If you liked this thing - let me know by putting like!

Parts links below:

• Industrial Syringe 3CC
• Threaded Rod Brass M3
• Insert Knurled Nuts M3
• Axial Thrust Ball Bearing F3-8M
• Black O Ring Gasket CS 2mm OD 9mm
• Steel Dispensing Needles Tips
• Button Head Screw iso7380 M2.5x16
• Luer Lock Adapter Coupler
• XD-Z40 No-Clean Mechanic Solder Tin Paste
• Syringe Adapter 3cc *
• Round Magnet 3x3 mm
• O-Ring 9x4x2.5mm
• TopZeal Filament ABS

Links to used tools:

• Thread Screw Tap M2.5
• Reamer Tool
• Drill Bit Set
• NOGA deburring tool and Blades
• Mini Wireless Grinder
• Angle grinder

Ready made:

• Flux Dispenser 10cc Alu
• Flux Dispenser 10cc

Required files:

• project-files.zip
