M4-AR-15 Upper vise block

Attention! This model should be fitted as precisely as possible to work correctly. To avoid excessive clearances caused by material shrinkage, I recommend scaling the model by the percentage value specific to the material you are using (Since the cooperating parts are on the inside, I recommend reducing the model's dimensions). If you notice excessive clearances in an already printed model, I recommend eliminating them, for example, by using electrical tape.

Exact dimensions of each AR-15 carbine may vary depending on the manufacturer. In case the holes don't align perfectly, I recommend using pins with a smaller diameter.
