Description

Overview

F-16 Kit Card with optional LED navigation lights & afterburner. Perfect for aviation enthusiasts that want to build and showcase their planes! Available in gray & camo paint with and without a frame.

Check out the full airplane kit card collection → linked here!

For building the LED version, you will need the single LED magnetic switch lights are available from MakerSupply. See BOM below to purchase.

1 warm white LED for afterburner
1 green LED for right navigation light
1 red LED for left navigation light

Profiles

AIR FORCE GRAY PROFILES

Kit With Frame (Gray)
- plane in a kit card format ideal for gifting to others
Kit No Frame (Gray)
- plane without a kit frame ideal for assembly right off the printer with 3 color plane (dark gray, black, & light gray missiles/tanks)
LED Kit No Frame (Gray)
- no frame format configured to use with magnetic switch LEDs from MakerSupply (red & green)
Small Kit No Frame (Gray)
- Scaled 75% with 0.16mm layer heights to maintain resolution

CAMO PROFILES

Kit With Frame (Camo)
- plane in a kit card format ideal for gifting to others
Kit No Frame (Camo)
- plane without a kit frame ideal for assembly right off the printer with 3 color plane (dark gray, black, & light gray missiles/tanks)
LED Kit No Frame (Camo)
- no frame format configured to use with magnetic switch LEDs from MakerSupply (red & green)
Small Kit No Frame (Camo)
- Scaled 75% with 0.16mm layer heights to maintain resolution

Note: Afterburner is set to use PETG Clear Filament. Clear PLA should work also but not tested.

Filament

As shown:

Gray Profiles
- eSun PLA+ Gray (airframe)
- Bambu Lab PLA Black (canopy & tail)
- Bambu Lab PETG Translucent Clear (afterburner only)
Camo Profiles
- Bambu Lab PLA Cyan (airframe)
- Bambu Lab PLA White (airframe)
- Bambu Lab PLA Light Gray (airframe & missiles)
- Bambu Lab PETG Translucent Clear (afterburner only)

Tips

Model requires close tolerances to ensure snug but not tight or loose fit
- Make sure the model cools to room temperature before assembly
- Ensure filament is properly calibrated with no excessive over extrusion
- If there is some over extrusion the parts may need to be lightly sanded at interfaces for fitment
Ensure good bed adhesion
- Make sure printer is fully calibrated
- Make sure print bed is clean & dry (soapy water is my favorite for cleaning - simple & works)
- Make sure filament is dry (wet filament can generate non-continuous flow that can cause bed adhesion issues)
- Cooling & Temps - make sure they are correct for your printer, build plate, and filament
- Smooth PEI plate is recommended

Assembly

Remove all pieces from the kit
Debur as needed to smooth edges
Insert clear translucent PETG filament into slot (optional, for LEDs) & trim to length (NOTE: Tight fit slot. Use pliers for leverage to push filament through slot).
Add LEDs to lower fuselage (optional)
Insert afterburner & warm white LED to upper fuselage (optional)
Insert bar into lower fuselage
Connect upper fuselage to lower fuselage
Insert vertical tail into upper fuselage slot
Insert missiles and fuel tank to the wing
Insert missiles onto wing at remaining slots
Insert missiles onto wing tip
Place aircraft onto stand
Enjoy!
