Description

the original wifi antenna holder that came with my Z790-P prime mobo is basically trash (maybe i'm not using it correctly, for which i'm glad to be enlightened). it keeps falling down and doesn't stand on itself.

i searched the internet and found this design https://www.thingiverse.com/thing:4565647 from the look of this, asus has been using this same antenna design for a while, and it fits my antenna perfectly, so I'd venture to say if your antenna “looks” like this, it should fit.

obviously i have to add the asus ROG logo to take advantage of the AMS, as well as made three hole sizes for those of you with different magnets on hand (10x2mm, 8x2mm, and 6x2mm)

you will notice my printed version had only two magnets, this is because i noticed a small amount of wobble with only two 10mm. didn't really bother me so i'll not re-print, but enough for me to go back and add another slot, so for those of you that needs extra security for the antenna, you have the option to use all three slots.

Comment & Rating (9)

@ennanco

Print Profile

0.24mm layer, 2 walls, 15% infill

The only improvement would be to include an additional layer with a pause to embed the magnets for a cleaner finish and to eliminate the need for glue.

@topxnbo

thanks for rating and the suggestion. I've actually never tried that technique (always concerned the magnet will get moved somehow after I place them and damage the printer >_<) will give it a shot when i get a chance.
