No TPU anti vibration feet - A1, A1M Remixed by Edna

Remixed by

Edna

3D Printer>3D Printer Accessories

IP Report

Print Profile(1)

All

A1 mini

0.2mm layer, 2 walls, 15% infill

Designer

2 h

2 plates

4.3(6)

Open in Bambu Studio

Boost

Released

Description

This is a remix adding A1 and A1M compatibility. I've tested on an A1M with PLA, so A1 and different filament mileage may vary.

Each pad has a slot for 4 clips, and I use 2 for an A1M except for the back left pad.

These clips are also cross compatible with the ones from the original model, including the soft springs.

Do a full calibration after adding. It may say your X resonance is low.

Comment & Rating (12)

@AlazDesign3D

Print Profile

0.2mm layer, 2 walls, 15% infill

quite usless need better design, without glue they are totally usless, could have mention that in the description, i would not wasted my time, also A1 has 6 legs (center also 2). also i think they are way too large. i give 1 star for trying at least, friendly advice, delete those and go back to the drawing board. no hate just honest.

@ednaordinary

sorry you feel that way :( I didn't need to glue them in with the ones I printed but it's likely not everyones tolerances are the same. Also make sure you are pushing them in all the way, they should show slightly on the inside. I don't have an A1 to test with so it's also possible the feet pads are smaller, otherwise I think they fit well on an A1M

@AlazDesign3D

Replying to @ednaordinary :

I don't know what A1M is. I glued them anyway yo try them out but i did not see much of a difference also with or without them, they under the printer rn and i will give them littlebit more time see if is can notice a difference, i did full calibration abd and my shelves still vibrated lile before specialy with the low hz.

@Strzigun

A1M is an A1 mini printer, I also have an A1 and it seems to me that your model is too weak for A1. A1 is larger and heavier which makes your pads useless in our case.

@andreitelteu

Boosted

The best anti-vibration solution I found so far ! Thank you ! No glue needed for me (printed in PETG). I made one extra pad for the corner where the filament spool is. I also connected 4 clips instead of 2 for better suport.

@ocwanwhispers93

Print Profile

0.2mm layer, 2 walls, 15% infill

A+. I superglued mine together. Maker should consider including 8 more clips so each foot can have 4.

@ednaordinary

The second plate has more clips. Glad it worked for you :)

@kubiik_7835433

Print Profile

0.2mm layer, 2 walls, 15% infill

good

@AlazDesign3D

without glue super usless, the clamps.just pop out not tight fit as they should be, got to give you 1 star just for trying but need better disain and more clamps 2 for each is def not enough.
