Description

Designed my own filament spool shelf in honeycomb design. There are 3 versions, for 1" inch wooden dowel, 23mm dowel and 20mm dowel. Used 2pcs M5 wall screws per bracket, spacing between top and bottom screw is 95mm. Its designed just to slid onto mounted screws, witch should have 5mm space between screw head and wall.

Added template for easier drilling holes and adjust right screw distance, also added plane if you want to you use spirit level.

Added endcap for those whom wooden dowel extends from shelf bracket to prevent filament spool tipping over. Also made divider so you can separate different type of filaments from each other on one shelf and not mixing them accidentaly. Here: https://makerworld.com/en/models/117747#profileId-126576

Also added filament material tags so you can separate different type of filaments from each other, here:

https://makerworld.com/en/models/117775#profileId-126618

Added accessories to utilize honeycomb holes for some holders. link here:

https://makerworld.com/en/models/1129702#profileId-1129747

Comment & Rating (1956)

@dustyd88

Print Profile

1" inch spool shelf, 0.2mm layer, 4 walls, 8% infill gyroid

Used Bambu PETG Black and Orange. Printed perfectly. Happy to get my spools organized! Printing another and end caps/dividers next!

The profile uploader has replied

@Maoirae

Nice colors 👍 Im glad you like it 🙂

@user_2921006142

how do you change the colors like that?

@dustyd88

Replying to @user_2921006142 :

It's in the paint settings. Check out this video:https://www.youtube.com/watch?v=5aJZyhfY74s

@rekk

Print Profile

20mm Spool shelf 0.2mm layer, 4 walls, 8% infill

Great print, very strong, looks good. I did black PETG with 3/4" wood dowels from Lowes.

The profile uploader has replied

@Maoirae

Im glad you like it

@ChristianL

Woher bekomme ich so eine Lampe? Oder hast du die selbst gemacht?

@O3Studios

Boosted

Just an FYI - I have taken this picture and made it the wallpaper on my desktop as motivation of the sharp clean style I want for my 3d print room.

@timschuette5

Print Profile

1" inch spool shelf, 0.2mm layer, 4 walls, 8% infill gyroid

worked really well. these things are beefy!

The profile uploader has replied

@Maoirae

Check my profile for divider and endcap for this spool shelf, also added filament tags :)

@dustyd88

Did you print with PLA? Wondering about strength on these with 48" dowels and being fully loaded.

@moberry16

Replying to @dustyd88 :

I think it's in PETG

@user_15532090

Print Profile

1" inch spool shelf, 0.2mm layer, 4 walls, 8% infill gyroid

great model and print profile. the mounting template is great for hardware spacing as well as setting the screw depths at the required 5mm for the keyholes in the bracket. Definitely solved my issue of keeping filament on the floor. My 1" dowel were 48" long and for added security i opted to add a 3rd bracket in the center. My wife is pleased to see the reduced clutter. happy spouse happy house. win win in my book 🤣

The profile uploader has replied

@Maoirae

Im glad you like it

@Bluedolph

Boosted

did you use drywall anchors or did you drill into the studs?

@Bradfish1983

Boosted

Replying to @Bluedolph :

Studs are always preferable

@AndyZi81

Print Profile

20mm Spool shelf 0.2mm layer, 4 walls, 8% infill

Clean storage place for 24-26 filament rolls as a beginning. I’m loving it! perhaps a third rack left of the door above the other one in the future!?

The profile uploader has replied

@Maoirae

I'm glad you like it. There is allways not enough space for filament :D

@Maoirae

Check my profile for divider and endcap for this spool shelf, also added filament tags :)

@AndyZi81

Replying to @Maoirae :

divider and signs printed.😉

@cammyowl

Boosted

Print Profile

1" inch spool shelf, 0.2mm layer, 4 walls, 8% infill gyroid

work great the only problem is my wife know knows how much filament I bought

@Leenyjb

Boosted

I am in heaven. We printed six of these brackets and partner bought the rods… now we have a dream filament storage system. Strong and it looks good too. Thank You.

(Edited)

The designer has replied

@Maoirae

Im glad you like it 🙂

@user_3639020806

What size EMT "ROD" are you using

@vipertech17

Printed 7 brackets in black pla-cf and look awesome. Great design. Would be great if you could make a separator or an end cap for this.

The designer has replied

@Maoirae

You mean some separator between spools attached to dowels?

@vipertech17

Replying to @Maoirae :

yes to separate pla from petg or carbon fiber etc. also for the ends if some people have the dowels sticking out passed the bracket to make like an end cap to stop rolls from possible falling off. just some suggestions.

@vipertech17

Replying to @Maoirae :

something like this

@Lige

Boosted

Print Profile

1" inch spool shelf, 0.2mm layer, 4 walls, 8% infill gyroid

Ten out of Ten! these are perfect. I used 3 spread across 5 feet. One 10 foot PVC pipe cut in half works great!

The profile uploader has replied

@Maoirae

Im glad you like it

@sanchezmj228

Awesome design and functionality! Feels sturdy and has a nice and clean look due to the hidden screw heads. Printed great in both PETG and ABS. This brackets were a life saver for my mess! Thanks! P.S: I know many people will be getting crazy about the AC vent near by the spools but don't worry it's closed and sealed haha.

(Edited)
