AMS Riser V4 is Here!

The AMS Riser V4 has arrived, retaining all the great features of V3 while introducing exciting new improvements. Enjoy dual-direction opening, increased height for X1C compatibility, and enhanced cable management.

Upgrade now for even greater flexibility and ease of use!

https://makerworld.com/en/models/999258#profileId-976329

New improved LED Strip holder added here:

Improved LED Strip Holder for AMS Slim Riser V3

https://makerworld.com/en/models/882366#profileId-836785

New and Final Version of My Slider for Glass/AMS

Significant changes and improvements have been made, including:

Protection against falling or tilting of the glass and AMS unit.
Added clamps that secure the riser to the printer's housing, preventing accidental detachment.
Improved LED mounting attachment, designed with an angle for optimal lighting of the build plate.
Added an optional stopper to prevent the glass from being opened too far.
Incorporated grooves on both sides for easy mounting of various accessories, such as hex panels (HSW), IKEA Skadis panels, and many other add-ons like tool holders.
Added labels on each part for easier assembly.

There are two available versions:

One where the glass opens towards the back, and
Another where the glass opens towards the front.

Bill of Materials
