Shorter! Case Friendly iPhone 12 to15 & Max Dock Remixed by mars730

Remixed by

mars730

Household>Decor

Print Profile(2)

All

X1 Carbon

P1S

P1P

X1E

A1 mini

Shorter! Case Friendly iPhone 12 to15

Designer

4.1 h

3 plates

4.9(28)

Shorter! Case Friendly iPhone 12 to15 Max

Designer

5.2 h

3 plates

4.8(8)

Open in Bambu Studio

Boost

156

874

298

Released

Description

Here’s a rephrased version:

"This is a more compact version of Scott Yu-Jan's iPhone 15 Pro Dock, without the AirPods charging section.

If you're looking to:

- save time
- save filament
- save space

this could be the perfect dock for you!"

You can find my standard Case Friendly model at the link below.

Case Friendly iPhone 12 to15 pro & Max Dock 二次创作 - 来自 mars730 - MakerWorld

The size has been modified to conveniently hold the iPhone with a case, and you can also download the f3d file to modify the dimensions in Fusion 360.

UPDATE：

I have confirmed that the size differences between the iPhone 12 to 15 models are minimal (as per the table below). Therefore, I updated the dock to accommodate the better iPhone models and adjusted the size to better support most iPhones with cases.

iphone Model	Length (mm)	Width (mm)	Tolerance Length (mm)	Tolerance Width (mm)	File name
iPhone 15 Pro Max	159.9	76.7 mm	165	82.6	iPhone 12-15 max with case
iPhone 14 Pro Max	160.7	77.6 mm
iPhone 14 Plus	160.8	78.1 mm
Phone 13 Pro Max	160.8	78.1 mm
iPhone 15 Pro	146.6	71.6 mm	153	78	iPhone 12-15 with case
iPhone 15	147.6	71.6 mm
iPhone 14 Pro	147.5	71.5 mm
iPhone 14	146.7	71.5 mm
iPhone 13 Pro	146.7	71.5 mm
iPhone 13	146.7	71.5 mm

UPDATE (2024/09/17)：

The f3d file has been uploaded. You can adjust the size yourself to create a short dock that fits your iPhone with a case.

Comment & Rating (92)

@user_2738393307

What’s the 3rd part for?

The designer has replied

@mars730

Test part. You can prioritize printing it to test the dimensions, in order to avoid wasting time and money.

@Klexl

Boosted

Print Profile

Shorter! Case Friendly iPhone 12 to15

very good, but i had to make an addon to make my iphone 12 fit perfektly

@user_849158521

Could you post the file for the addon please? My iphone 12 won't fit either, and I don't really know how to do 3d modelling lol.

@Klexl

Boosted

Replying to @user_849158521 :

i uploaded it, i hope it works for you aswell. Maby youd like to also try out my boxes or have any other idea that would be usefull that i could modell. Thank you

@amateurprinter

Three pictures speak more than three thousand words.

@chenyi1976

Print Profile

Shorter! Case Friendly iPhone 12 to15

nice. a bit loose. but works ok.

@acevalsl

Print Profile

Shorter! Case Friendly iPhone 12 to15

Perfect print, but it's too small for the mobile phone

Show original

@presantg

Boosted

Print Profile

Shorter! Case Friendly iPhone 12 to15

looks good

@DigiPaws

Boosted

Print Profile

Shorter! Case Friendly iPhone 12 to15

Works really well and the Apple Magsafe charger fits in it really well, you will need to get some double-sided tape to stick the Magsafe Charger in. You will also either need double-sided tape or non-slip pads to stop the dock from moving around. In my images, I had stuck a Fitbit Charger Holder to the side but that is not apart of the dock.

@Alethi

Print Profile

Shorter! Case Friendly iPhone 12 to15

came out lovely, thanks!

@nert_v

Although the model does not fit the 15 pro max perfectly, it can be used without impact on functionality. You can ajdust the frame or print frame that will fit inside and make it perfect.

(Edited)
