Dummy 13 Wings Remixed by carbon black

Remixed by

carbon black

Miniatures>Other Miniatures

IP Report

Print Profile(2)

All

P1S

P1P

X1 Carbon

X1E

A1 mini

0.15mm layer, 2 walls, 20% infill

Designer

3.7 h

1 plate

4.4(131)

0.15mm layer, 2 walls, 20% infill, re-arranged for a speedup

3.3 h

1 plate

4.8(12)

Open in Bambu Studio

Boost

1222

2783

183

3.2 k

1.3 k

Released

Description

Wings for Dummy 13

Wings for Dummy 13! The huge pairs of wings are designed to be attached to the back of dummy 13 using the standard ball joint. So the wings can be rotated to a degree.

However, because of its size and weight, you'll need dummy with rigid joints to withstand the weight. I printed mine in PLA so the joints became loose quite quickly, so I remixed a display stand that can be attach to the wings for stablity.

Get your Dummy 13 display stand here:

https://makerworld.com/en/models/497089#profileId-411479

Get your base Dummy 13 model here:
https://makerworld.com/en/models/183780?from=search#profileId-202639

Please Boost the model if you like it!

Comment & Rating (183)

@user_2293896563

Mine both snapped off the second I tried to insert the ball joint. Bambulabs PLA.

@Tripi

i had exactly the same issue, happened with 3 wings. I used PETG.

(Edited)

@user_2293896563

Replying to @Tripi :

awe was thinking of using Petg next. Thanks for the heads up.

@trebz

same issue for me :-(

@PawloMaker3D

The wings are amazing!!! I slightly increased the hole for better fastening of the wings made of PLA filament by 0.3 mm. The clasp no longer breaks.

@Spacedfallen

I’d be more than thankful if you made a remix with your solution!

@PawloMaker3D

I'll put up a remix tomorrow

@user_3360832865

Boosted

Replying to @PawloMaker3D :

SO IT HAPPENED 😄😄😄😄😄

@itsPaul19

Print Profile

0.15mm layer, 2 walls, 20% infill

printed perfectly without any flaws, putting it together was a bit difficult but I used a lighter to soften the plastic and then it worked just fine. I glued the wings in place because they started hanging down more and more due to their own weight

@Zodox

Print Profile

0.15mm layer, 2 walls, 20% infill

Lovely

@duder

Looks great! I was ready for a movie trailer!!

@SofaKingNerdie

Print Profile

0.15mm layer, 2 walls, 20% infill

they look so beautiful

@DiscountLlama

Print Profile

0.15mm layer, 2 walls, 20% infill

Left wing clip consistently snaps and breaks

@Freebie_From3D

try a softer plastic like PETG, abs might be too soft and might wear out on grip too soon.

@user_2279673312

Replying to @Freebie_From3D :

imma try printing in petg next. I’ve done abs and pla. both snapped but i might just glue them. my biggest issue is the mount for the wings doesn’t stay in the body. and sticks out too far imo

@user_495231180

brilliant model, however the clips have a tendency to... snap. I scaled it up by 1% and it popped in just fine!

@Vuldriel_Zastek

Print Profile

0.15mm layer, 2 walls, 20% infill

Printed in tri-color silk PLA and it looks amazing but I should have make the joint section out of normal PLA because the ball-joint snapped. This is not the fault of the model but the material I chose.
