A GIANT Pinball Flipper Bat as a lightbox with Williams logo

Check out my other light box in the same series(picture on the right)

This model is a decent copy of a real pinball flipper bat.
It is scaled up to 360% in Bambu Studio so the LED lights can fit in it. Perfect to hang on the wall in your pinball room/man cave.

Its printed in PLA Tough but normal PLA should work as well. The white front of the flipper bat is quite thick so the light can diffuse. Use bright LEDs.

The backside lid of the flipper bat can be printed in PLA as well but I printed mine in PETG so it doesn't crack when I screw it to the wall.

I highly recommend using the print profile I created. Otherwise, there is a big risk that some details will not be visible.

You can use Bambu Labs LEDs or buy ones of your choice.

Boost Me (for free)

Thanks for supporting me!

Bill of Materials

Maker’s Supply Kits and Parts

2PCS 4 White 3030-LED Board with SH1.0 Connector 5V - KB001

B-KB001

3.99 USD

× 3

Bambu Filaments

Red

A00-R0-1.75-1000-SPLFREE

19.99 USD

× 1

Jade White

A00-W1-1.75-1000-SPLFREE

19.99 USD

× 1

Black

A00-K0-1.75-1000-SPLFREE

19.99 USD

× 1

Buy Now

Download BOM

Comment & Rating (45)

@GHOSTELEVEN

Boosted

Great design. Do you have a model that would be a right side flipper?

The designer has replied

@CEMS

Yes! But that is a Bally logo. https://makerworld.com/models/464463

@GHOSTELEVEN

Boosted

Replying to @CEMS :

Do you have any plans to make both sides for the flippers? I think it would look cool to mount two of them on the wall each side. Thanks.

@CEMS

Replying to @GHOSTELEVEN :

like that?

@TotallyJuvenile

Boosted

I am looking to print this a bit quicker, I just wanted to know why the layers for the RED part, aren't red inside? It would reduce 4 hours and some filament to not have all the filament changes.. Does having the white inner layers affect the reflectiveness of the light?

The designer has replied

@CEMS

I understand what you mean by reducing printing time. Actually didn't think that far when I drew the model. But if it is red on the inside, the red can probably shine through even where it should be white.

@TotallyJuvenile

Boosted

Replying to @CEMS :

I went ahead and made this modification, just painted the layers for the bumper all the way through. it turned out awesome and saved 4 hours for each flipper. Thanks for getting back to me though. You made an awesome lightbox here! I used some off white led strips to give it an older look and it turned out exactly as I hoped!!!

(Edited)

@CEMS

Replying to @TotallyJuvenile :

nice

@user_896605158

Boosted

Print Profile

0.2mm layer, 2 walls, 15% infill

@CEMS

👍

@user_4232945427

Print Profile

0.2mm layer, 2 walls, 15% infill

printed great thank you

@CEMS

Thanks!

@TotallyJuvenile

Boosted

First boost token I have given out... Love these signs! Do you have or did you follow any tutorials on how you made these?

The designer has replied

@CEMS

Thanks! No, I took some measurements of an original pinball bat and drew it in Fusion. Found the logo of williams and balley online. Inserted them and made some adjustments.. hard to explain.

@user_1985852041

Boosted

Print Profile

0.2mm layer, 2 walls, 15% infill

Printed on my X1C with AMS, this required a slight tweaking to settings due to having an issue with the thin script font lines between letters. I had to mess with the Detect Thin Wall setting to alleviate the issue.

@CEMS

Strange… In my print profile detect thin walls and Arachne wall generator is activated.

@user_1985852041

Boosted

More pinball signs, fantastic job!

@webdeck

Boosted

Nice!

The designer has replied

@CEMS

Thanks!

@Wombatinahat

Print Profile

0.2mm layer, 2 walls, 15% infill

Stunning model and it printed beautifully! Thanks a lot!

@Cheech1977

Boosted

Superb! Magnificent! Will be great next to my virtual pinball

The designer has replied

Show original

@CEMS

Thanks
