Ultimate Spool Series

I had problems with the spools already published and I needed some practice in Fusion so i started to make my own filament spool from scratch. I print nearly everything with AMS, so I needed a AMS Bambu filament spool with the following propertys:

Clip integrated (clickable clip), fixes filament within the first 20 mm
Tight lock mechanism
Very good result with "only" PLA
Respool inserting points
a scale
stable but possible lightweight
Label integrated and changeable
optimized for 3d printing on every edge
no supports

The spool was tested in AMS and printed with a P1S in PLA and with 0,20mm standard profile. No need to make any changes.

A big insparation was the work of @KobaRiley with his ClipSpool V2 . I liked the idea of having the clips integrated and the changeable labels so much, that it was a must have. Thanks for that

integrated second clickable clip for respooling ( left and right of the “nose”

both sides are “empty” in the body but very stable through structure. You can also see the scale on thes render. It goes from 10 - 100 %

Versions

Bambu Refills
- Side 1 with label - Side 2 with or without Scale
- Side 1 and 2 with label and scale
ESUN, Polymaker and Overture Refill

Labels

There are a few finished labels in the Folder Labels you can instant use. If you want to have your own Textstyle or whatever :D please feel free to use the .step file to create your own in CAD or you can also use my predefined Make a Sign Template.

Download json templatefile: This One
Go to Make my Sign Page
Click “Create from Blank” (On top right corner)
In the dialog “Start with Template”, click “Import template(JSON file) >”
Select the downloaded file from step one from your filesystem
Accept change diolog
Change the Text like you want it
Download your customized Sign
Assemble a blank Label with your new Sign

Here is a video how to make the Label from the sign:

Feedback Welcome

Please let me know if you have any requests. It would also be nice to have a lot of feedback. Cheers

Updates

03.09.2024 - New variant with all features on both sides - Thanks 2 @Groucho

02.09.2024 - New smaller variant of spool for ESUN, Polymaker and Overture Refills - Thanks 2 @Jacannwilson

17.07.2024 - Thanks 2 @deniskenntjeder for the info of the corrupt file :D - Updated that

28.03.2024 - Needed a LabelRack for my HoneyCombWall - So I added it to the Raw files for you too.
