Description

This is a small clamp with extremely strong clamping force. Based on my previous clamp design, it retains the spring-loaded jaw mechanism, which can hold some thick and hard objects. The clamping and locking mechanism has been redesigned, featuring a vise-style lever mechanism with screw and nut adjustment for opening and clamping force. Compared to other 3D printed clamps, its clamping force is exceptional and will not decrease due to material deformation. Its maximum clamping force depends on the material's tensile strength.

The clamp is very lightweight, requiring only 13g of filament and no supports needed for printing.

It consists of 3 parts and is easy to assemble for use.

It is fully 3D printed, with no additional materials required.

Both PLA and PETG materials can be used for printing, but PETG is more recommended as it has higher toughness and is less likely to suffer from permanent deformation.

Assembly steps follow:

The light version is now available, weighing just 9 grams, with wider tooth spacing, perfect for gripping fabrics while maintaining a strong hold.

Comment & Rating (109)

@user_3914471457

Boosted

This is the best clip I've found on here - it holds tightly and is easy to print. I also like that it has 3 (easy to assemble) parts because it allows for a more interesting color combination.

The designer has replied

@Joywent

Thank you for the great review and the boost! However, from the image provided, it seems that the yellow housing in the middle appears to be installed backward.

@user_3914471457

Boosted

Replying to @Joywent :

You're right, thank you! I fixed it.

@user_2495282067

It printed and functionality so perfect! Excellent design. I will print more to replace my old clips. Thank you!

The designer has replied

@Joywent

Thank you for the review!😄

@Prints_for_fun

Boosted

Print Profile

Light version

These are awesome and something I didn’t know I needed. Simple design and it works amazingly! Designer did a fantastic job on these and they scale very well. I made a few that were 50% and 75% of the original. I printed both versions. Printed out of PETG for a little more strength and longevity.

@Joywent

Thank you for the great review!👍🏻😄

@Bonjomon

Boosted

Prints great on my P1S. Feels sturdy. I used it to hang my winter gloves and face mask after using the snow blower.

(Edited)

The designer has replied

@Joywent

Thank you for your comments and sharing its use case. I'm glad to see it's capable of handling this task. Thank you especially for your boost!😄

@user_3108603171

Boosted

Print Profile

Standard Version

Prints exceptionally well on my P1S Feels robust Very strong clamp

Show original

@freekkiprkl

Boosted

Print Profile

PLA, Two Plates, Two Colors, Stronger Clamp Part

seems sturdy and printed great!

@user_2156779139

Print Profile

standard 2 Plates PLA version

Nice :)

@Rafiki2085

Print Profile

0.6mm nozzle, 0.18mm layer, 2 walls, 15% infill

solid print, goes together well.

@dj_ste

Boosted

Print Profile

Light version

Ottimo

@ihgedasila

Print Profile

Standard Version

nice design
