Hello everyone,

I have vectorised a technical drawing of one of the first 3D printing patents and made it printable with a 0.4 nozzle.

IMPORTANT:

The illustration is very detailed, so slicing can take up to 5-10 minutes!
Please note the settings in the screenshot

If you have any problems, just write to me

Boost Me (for free)

Do you like it? Then I would be very happy about a boost.
